Pillar

Aluminum railing system
  • Modern, low rise, rectangular handrail profile
  • Low Maintenance and engineered to last
  • Requires basic assembly with easy-to-follow instructions
  • Designed for professional installers and DIYers
  • Meets the National Building Code of Canada 2020
  • Pillar USA Rail kits meet ICC-IRC (International Residential Code)

*Consult your local building codes before starting a project.

Pillar
Pillar
Pillar
Pillar
Pillar
Pillar

Product Documents

Pillar Brochure Pillar Rail Instruction Canada Pillar Rail Instruction USA Pillar Ang Bracket Instruction Canada Pillar Ang Bracket Instruction USA Pillar Gate instruction Canada

COMPLETE YOUR INSTALLATION IN A FEW SIMPLE STEPS

Note: spindle attachment fits both straight and stair applications. For stair installation, must use 36" high rail.

1. Determine right location to install posts
2. Install spindle attachment to post
3. Cut and attach to rails
4. Snap spindles into place

Specifications

STRAIGHT RAILING KITS

Item No.Description
KD103648W-APillar Straight / Stair Railing 36"x48" White Pebble
KD103660W-APillar Straight / Stair Railing 36"x60" White Pebble
KD103672W-APillar Straight / Stair Railing 36"x72" White Pebble
KD104248W-APillar Straight Railing 42"x48" White Pebble
KD104260W-APillar Straight Railing 42"x60" White Pebble
KD104272W-APillar Straight Railing 42"x72" White Pebble
KD104860W-APillar Straight Railing 48"x60" White Pebble


GLASS RAILING KITS

Item No.Description
KD10G4248WPillar Glass Railing 42x48 White Pebble
KD10G4272WPillar Glass Railing 42x72 White Pebble

GATE KITS

Item No.Description
KD0469Pillar Gate Kit 36"H x 42" for 2.5" Post White Pebble
KD0473Pillar Gate Kit 42"H x 42" for 2.5" Post White Pebble
KD0476Pillar Gate Kit 48"H x 42" for 2.5" Post White Pebble


POSTS

Item No.Description
P203725PTBMounting Post 2.5" x 37.5" White Pebble - Plastic T/B
P204025PTBStair Post 2.5" x 40.5" White Pebble - Plastic T/B
P204325PTBMounting Post 2.5" x 43.5" White Pebble - Plastic T/B
P204925PTBMounting Post 2.5" x 49.5" White Pebble - Plastic T/B


STRAIGHT RAILING KITS

Item No.Description
KD103648BP-APillar Straight / Stair Railing 36"x48" Black Pebble
KD103660BP-APillar Straight / Stair Railing 36"x60" Black Pebble
KD103672BP-APillar Straight / Stair Railing 36"x72" Black Pebble
KD104248BP-APillar Straight Railing 42"x48" Black Pebble
KD104260BP-APillar Straight Railing 42"x60" Black Pebble
KD104272BP-APillar Straight Railing 42"x72" Black Pebble
KD104860BP-APillar Straight Railing 48"x60" Black Pebble


GLASS RAILING KITS

Item No.Description
KD10G4248BPPillar Glass Railing 42x48 Black Pebble
KD10G4272BPPillar Glass Railing 42x72 Black Pebble


GATE KITS

Item No.Description
KD0470Pillar Gate Kit 36"H x 42" for 2.5" Post Black Pebble
KD0474Pillar Gate Kit 42"H x 42" for 2.5" Post Black Pebble
KD0477Pillar Gate Kit 48"H x 42" for 2.5" Post Black Pebble


POSTS

Item No.Description
P21P3725PTBMounting Post 2.5" x 37.5" Black Pebble - Plastic T/B
P21P4025PTBStair Post 2.5" x 40.5" Black Pebble - Plastic T/B
P21P4325PTBMounting Post 2.5" x 43.5" Black Pebble - Plastic T/B
P21P4925PTBMounting Post 2.5" x 49.5" Black Pebble - Plastic T/B


GLASS PANELS

Item No.Description
KD0506Clear Tempered Glass 36.5"x15" for 42" Rail 5mm
KD0497Clear Tempered Glass 36.5"x33" for 42" Rail 5mm
KD0498Clear Tempered Glass 36.5"x39" for 42" Rail 5mm
KD0499Clear Tempered Glass 36.5"x45" for 42" Rail 5mm
KD0500Clear Tempered Glass 36.5"x51" for 42" Rail 5mm
KD0501Clear Tempered Glass 36.5"x57" for 42" Rail 5mm
KD0502Clear Tempered Glass 36.5"x63" for 42" Rail 5mm



SCREWS

Item No.Description
KD0076-AScrews Hex/Tek 1 1/4" White (50/pk)
KD0129-AScrews Hex/Tek 1/2" White (50/pk)
KD0169-AScrews Hex/Tek 1 1/4" Black (50/pk)
KD0172-AScrews Hex/Tek 1/2" Black (50/pk)


BRACKETS

Item No.Description
KD0479Pillar Angular Bracket Set White
KD0467Pillar Angular Bracket Set Black Pebble


SPINDLE FITTINGS

Item No.Description
KD0487Pillar Spindle Fitting 36" (2/pk) White
KD0488Pillar Spindle Fitting 36" (2/pk) Black Pebble
KD0490Pillar Spindle Fitting 42" (2/pk) White
KD0491Pillar Spindle Fitting 42" (2/pk) Black Pebble
KD0493Pillar Spindle Fitting 48" (2/pk) White
KD0494Pillar Spindle Fitting 48" (2/pk) Black Pebble


POST BASE COVERS

Item No.Description
KD0481Base Cover 2.5" x 2.5" White - Plastic
KD0482Base Cover 2.5" x 2.5" Black Pebble - Plastic
KD0484Post Cap 2.5" x 2.5" White - Plastic
KD0485Post Cap 2.5" x 2.5" Black Pebble - Plastic


PEG LEG

Item No.Description
KD0046Peg Leg White
KD0427Peg Leg Black Pebble


WHITE PEBBLE

STRAIGHT RAILING KITS
Item No.Description
KDUS103648WPPillar Straight Railing 36"x48" White Pebble US/ES
KDUS103672WPPillar Straight Railing 36"x72" White Pebble US/ES

POSTS
Item No.Description
PUS20P3725Mounting Post 2.5" x 37" White Pebble US/ES
PUS20P4025Stair Post 2.5" x 40" White Pebble US/ES


ACCESSORIES

SPINDLE FITTINGS
Item No.Description
KDUS0470Spindle Fitting (2/pk) White Pebble US/ES

BRACKETS
Item No.Description
KDUS0468
Pillar Angular Bracket Set White Pebble US/ES
KDUS0472
Pillar Wall Bracket Set White Pebble US/ES

POST BASE COVERS
Item No.Description
KDUS0452
Base Cover 2.5" x 2.5" White Pebble US/ES

BLACK PEBBLE

STRAIGHT RAILING KITS
Item No.Description
KDUS103648BPPillar Straight Railing 36"x48" Black Pebble US/ES
KDUS103672BPPillar Straight Railing 36"x72" Black Pebble US/ES

POSTS
Item No.Description
PUS21P3725Mounting Post 2.5" x 37" Black Pebble US/ES
PUS21P4025Stair Post 2.5" x 40" Black Pebble US/ES


ACCESSORIES

SPINDLE FITTINGS
Item No.Description
KDUS0469Spindle Fitting (2/pk) Black Pebble US/ES

BRACKETS
Item No.
Description
KDUS0467
Pillar Angular Bracket Set Black Pebble US/ES
KDUS0471
Pillar Wall Bracket Set Black Pebble US/ES

POST BASE COVERS
Item No.Description
KDUS0426
Base Cover 2.5" x 2.5" Black Pebble US/ES
